Bearing 6209-2RS

6209-2RS single-row deep groove ball bearing, rubber sealed on both sides. 45 mm bore, 85 mm outside diameter, 19 mm width, 0.41 kg. Replacement for the FM WORLD 4LZ-4.0E / 4LZ-6.0P (Ruilong) combine harvester. In stock, ready to ship.

Bearing 6209-2RS — 45 x 85 x 19 mm for FM WORLD 4LZ-4.0E / 4LZ-6.0P (Ruilong)

The 6209-2RS is the 45 mm-bore member of the 62 series: an outside diameter of 85 mm and a 19 mm width with rubber seals on both sides. On the FM WORLD 4LZ-4.0E and 4LZ-6.0P it covers medium-load shaft positions where a 45 mm shaft has to run at speed with little maintenance.

Specifications

Part number6209-2RS
Typesingle-row deep groove ball bearing, rubber sealed on both sides
Bore diameter45 mm
Outside diameter85 mm
Width19 mm
Weight0.41 kg
FitsFM WORLD 4LZ-4.0E / 4LZ-6.0P (Ruilong)
AvailabilityIn stock, ready to ship

Bearing type and load capacity

The 62 series sits between the thin-section 60 series and the heavy 63 series. At 45 mm bore it carries noticeably more load than a 6009 of the same bore, while taking less space than a 6309. The double rubber seal keeps the factory grease in and blocks the chaff and dust that a combine throws at every bearing on the machine.

Compared with the 6309 on the same 45 mm shaft

The 6309 shares the 45 mm bore but steps up to 100 mm outside diameter and 25 mm width. Where the housing allows only 85 mm, the 6209-2RS is the correct choice; where the shaft load is heavier and space permits, the 6309 takes it. Do not substitute one for the other without checking the housing bore.

Fitting notes

Press on the inner ring only. Driving through the outer ring brinells the raceway and shortens the life of a sealed unit that cannot be relubricated.

Before you fit it

Shaft and housing

The journal here is 45 mm and the housing bore 85 mm. Look for a wear step where the old ring sat; a scored journal will ruin the new fit long before the seal gives out.

Signs it needs replacing

  • Rumbling that rises with shaft speed and disappears when the belt is slackened
  • Visible grease staining around the seal lip
  • A wobble felt when the shaft is rocked by hand
  • Scoring or a blue tint on the shaft journal after removal

Compatibility and cross reference

Models covered

This bearing is the part listed for the 4LZ-4.0E and the 4LZ-6.0P, so one stock line covers both machines.

Confirming the right part

Order by the number on the old part together with the 85 mm bore. If the bore measures 100 mm you are looking at a 6309, not this bearing.

Questions we are asked about this bearing

Does the 2RS seal mean it is maintenance free?

Yes. Both sides are sealed and greased for life, so there is no relubrication interval.
