Blade, Fan (W2.5K-02HX-05-08)

cleaning fan blade. In-stock replacement for the FM WORLD header. Order by part number; contact us for exact fitment.

Fan Blade W2.5K-02HX-05-08 — 805 x 120 x 20 mm

This is a blade for the cleaning fan on the FM WORLD 4LZ-4.0E, an 805 x 120 x 20 mm vane weighing 0.9 kg. The fan set produces the air stream that separates light chaff from grain, and each blade is shaped to move that air efficiently. A damaged or worn blade unbalances the fan and weakens the cleaning airflow.

Specifications

Part numberW2.5K-02HX-05-08
TypeCleaning fan blade
Length x width x thickness805 x 120 x 20 mm
Weight0.9 kg
FitsFM WORLD 4LZ-4.0E Combine Harvester
AvailabilityIn stock, ready to ship

What this part does

A fan blade is an aerodynamic part, not a cutting edge. Its pitched face accelerates air as the fan rotates, and the blades are balanced as a set. When one blade bends or loses material, the fan goes out of balance and the air volume across the sieve drops, which shows up as dirty grain rather than a cutting fault.

Fan blade versus the cutting and scraping blades

The knife and cleaning blades work by contact with crop or a surface; this fan blade never touches the material, it moves air. It is replaced for bending, cracking or imbalance, not for a dull edge, and it belongs to the cleaning system rather than the cutter bar.

Fitting notes

Fit the blade on a clean, secure mount and confirm all blades are at the same pitch and tightness so the fan stays balanced. The mounting is kept clean and the full set is checked together; replacing one blade on a damaged or unbalanced rotor without checking the others will not restore smooth running.

Before you fit it

Before fitting, inspect the rotor and all other blades for damage and check the fan bearings, since vibration can come from a bearing rather than a blade.

Signs it needs replacing

  • A bent or cracked blade that puts the fan out of balance
  • Vibration or noise from the fan housing at speed
  • Reduced airflow leaving chaff in the grain sample
  • A loose or fretted blade mount that lets the pitch change

Compatibility and cross reference

Models covered

Fits the FM WORLD 4LZ-4.0E cleaning fan; confirm the 805 mm blade and part number before ordering.

Confirming the right part

Match the number W2.5K-02HX-05-08 and the 805 mm length. This is an air-moving fan blade, not a cutter knife.

Reading the old part

The blade’s length is what settles it: 805 mm long, 120 mm wide, 20 mm thick, 0.9 kg. A blade straightened after a stone strike will still bolt on, but it reads short at one end when laid against the new one, so measure both ends rather than the middle.

Questions we are asked about this part

Should fan blades be replaced as a set?

If one blade is damaged, inspect every blade and the rotor. Replacing the damaged vane is enough when the rest are sound and the fan runs smooth, but balance must be checked before returning it to work.
