Feeder Drive Sprocket 5T078-4612-0 for Kubota DC70 Header Conveyor
Replacement feeder drive sprocket for the Kubota DC70 header conveyor. The live product record identifies this part as a feeder drive shaft sprocket, and the DC70 parts catalogue lists 5T078-4612-0 in the feeder drive section.
Feeder Drive Sprocket Data
| Part Number | 5T078-4612-0 |
| Component | Feeder Drive Sprocket |
| System | Header conveyor feeding drive |
| Machine | Kubota DC70 |
| Brand Line | Kubota replacement part |
| Selection Basis | Part number, feeder drive position and chain engagement |
Role in the DC70 Feeder Drive
This sprocket belongs in the feeder drive path and engages the feeder drive chain. It transfers rotation from the drive shaft so the feeder mechanism can pull crop from the header into the machine.
Comparing the Removed Sprocket
Compare the removed component by part number, shaft mounting position, and chain engagement. A tooth count is not recorded in the source data, so selection should not be based on an assumed tooth count.
Fitment Scope for 5T078-4612-0
This replacement page supports Kubota DC70 only. Earlier broad fitment statements are not carried forward because they are not verified for this batch.
If the old part shows a different number or suffix, send the complete marking for confirmation before ordering.
Feeder Sprocket Wear Checks
- Hooked or damaged teeth that prevent clean chain engagement
- Worn bore or loose fit on the feeder drive shaft
- Chain skipping or irregular feeder movement
- Damaged keyway, cracks, or chipped tooth edges
Ordering Information for the Feeder Drive Sprocket
Mounting: Kubota DC70 header conveyor feeder drive position.
Confirmation: Confirm 5T078-4612-0 on the old part or parts listing and match it to the feeder drive position.
Dimensions to match: No verified dimensional value is recorded. Use the part number and mounting position rather than estimated dimensions.
Related Header Conveyor Parts
Feeder Drive Sprocket Questions
Is this the complete feeder drum?
No. This product is the feeder drive sprocket, not a feeder drum or full assembly.
Can it be selected by machine model alone?
Model alone is not enough. Verify the part number and the feeder drive position before ordering.
Identification of 5T078-4612-0 before ordering
Use 5T078-4612-0 when the DC70 feeder drive sprocket is worn, damaged, or causing chain skipping. The part number should be checked against the removed component.
