Bearing PHSA10 — 10 mm Bore Housed Unit for FM WORLD 4LZ-4.0E Combine Harvester
The PHSA10 is not a loose bearing but a complete housed unit: a sealed insert bearing with a 10 mm bore is already mounted in a cast housing that bolts straight to the frame. On the FM WORLD 4LZ-4.0E this gives a ready-to-fit support for a small 10 mm shaft without machining a separate housing.
Specifications
| Part number | W2.5DA-07E-04-21L |
|---|---|
| Type | Pillow block (housed) bearing unit, self-aligning |
| Bore diameter | 10 mm |
| Unit outside diameter | 30 mm |
| Housing length | 75 mm |
| Weight | 0.05 kg |
| Fits | FM WORLD 4LZ-4.0E Combine Harvester |
| Availability | In stock, ready to ship |
Bearing type and load capacity
The insert has a spherical outside diameter that sits in a matching housing bore, so the unit can self-align and tolerate a small angular error in the frame. The housing carries the mounting bolts and the insert carries the shaft, which is why the part is ordered and replaced as one assembly.
Housed PHSA10 unit against a bare 6000-size bearing
A bare bearing needs a housing machined into the machine and a way to hold it in place; the PHSA10 supplies both, with bolt holes and a finished seat already in the part. Where the frame offers a flat mounting face and a 10 mm shaft, the housed unit is the faster, more forgiving fit. It is not a substitute where the design calls for a bearing pressed into an existing bore.
Fitting notes
Bolt the housing down squarely and let the insert self-align before tightening the shaft fit. Overloading the mounting or locking the spherical seat removes the alignment the unit is built to provide.
Before you fit it
Shaft and housing
Check the mounting face is flat and the bolt holes are not elongated. A housing bolted to a distorted frame cannot self-align enough to compensate.
Signs it needs replacing
- A loose housing that lets the whole unit move on its bolts
- The insert turning inside the housing instead of supporting the shaft
- A seized spherical seat that can no longer self-align
- Grease or dust tracking out through the insert seal
Compatibility and cross reference
Models covered
This housed PHSA10 is the part listed for 10 mm shaft supports on the FM WORLD 4LZ-4.0E.
Confirming the right part
Use the part number to order and confirm the 10 mm bore. The bolted housing and the 10 mm seat identify the PHSA10 unit.
Questions we are asked about this part
Do I replace just the insert or the whole unit?
The part is supplied and fitted as one housed assembly. If the housing or its bolt holes are worn or distorted, replace the complete unit rather than pressing in a new insert.
