Bearing 6305-2RS

6305-2RS single-row deep groove ball bearing, rubber sealed on both sides. 25 mm bore, 62 mm outside diameter, 17 mm width, 0.23 kg. Replacement for the FM WORLD 4LZ-4.0E / 4LZ-6.0P (Ruilong) combine harvester. In stock, ready to ship.

Bearing 6305-2RS — 25 x 62 x 17 mm for FM WORLD 4LZ-4.0E / 4LZ-6.0P (Ruilong)

At 25 mm bore and 62 mm outside diameter, the 6305-2RS is the heavy-section choice for a small shaft. It is sealed both sides and greased for life, so it suits positions on the FM WORLD 4LZ-4.0E and 4LZ-6.0P that are awkward to reach for lubrication.

Specifications

Part number6305-2RS
Typesingle-row deep groove ball bearing, rubber sealed on both sides
Bore diameter25 mm
Outside diameter62 mm
Width17 mm
Weight0.23 kg
FitsFM WORLD 4LZ-4.0E / 4LZ-6.0P (Ruilong)
AvailabilityIn stock, ready to ship

Bearing type and load capacity

The 63 series uses bigger balls and thicker rings than 60 or 62 at the same bore, which raises both radial and axial capacity. That makes this a good fit where a 25 mm shaft sees impact load and the housing can take a 62 mm bore.

Three 25 mm-bore options: 6005, 6205 and 6305

Three deep groove bearings share this 25 mm bore, stepping up in outside diameter from 47 to 52 to 62 mm. This part is the 62 mm version and therefore the strongest of the three, so a housing bored for 47 or 52 mm simply cannot take it. Choose by the bore you actually have, not by the number that looks familiar.

Fitting notes

Do not over-press the seal against a rough housing face. A seal running against a scored surface will pass dust within a few hours of work.

Before you fit it

Shaft and housing

A 25 mm journal inside a 62 mm bore needs a round housing. Press a sealed ring into an out-of-round bore and the seal will leak at the tight spot.

Signs it needs replacing

  • Continuous hum that turns into a knock under load
  • Seal rubber cracked or hardened by heat
  • A ring of dark grease at the housing joint
  • A shaft journal that is visibly worn where the inner ring sat

Compatibility and cross reference

Models covered

One number serves the 4LZ-4.0E and the 4LZ-6.0P, and it is the sealed ball bearing option in this size.

Confirming the right part

Read the old number, then measure the bore. At 52 mm the part is a 6205; at 62 mm it is this 6305.

Questions we are asked about this bearing

Is a 6305-2RS stronger than a 6205-2RS?

Yes, at the same 25 mm bore the 6305 has a larger outside diameter and carries more load, but it needs a 62 mm housing bore instead of 52 mm.
