Motor (W2.5B-04BX-12-03B-01)

Part W2.5B-04BX-12-03B-01. In stock for FM WORLD 4LZ-6.0P. Order by part number, contact us for fitment help.

Electric Motor W2.5B-04BX-12-03B-01 (340 x 120 x 120 mm, 10.2 kg) for FM WORLD

This electric motor, 340 x 120 x 120 mm and 10.2 kg, provides the drive for its assigned function on the harvester and works with the matching motor module.

Motor data

Part numberW2.5B-04BX-12-03B-01
ComponentElectric motor
Overall dimensions340 x 120 x 120 mm
Mass10.2 kg
SystemElectric drive

Providing the drive

The motor converts electrical power into rotation to drive the assigned component, with the separate module controlling its operation.

Motor against the motor module

This is the heavy rotating motor itself at 10.2 kg; the motor module is the lighter electronic unit that controls it, and the two are separate parts.

Mounting the motor

Bolt the motor to its mount, connect the plug and any output coupling, and confirm the fixing and alignment are correct.

After fitting, run the motor briefly and confirm it turns smoothly without unusual noise or excessive heat.

Motor and bearing wear

  • Bearings wearing and becoming noisy
  • Slow or weak rotation
  • Motor failing to start
  • Overheating in use
  • Worn internal components
  • Mount or coupling damage

Ordering checks

Mounting: Electric drive motor for FM WORLD combine electrical systems.

Confirmation: Quote the W2.5B-04BX-12-03B-01 number and confirm the 340 x 120 x 120 mm body and 10.2 kg mass.

Dimensions to match: Match the mounting, connector and output coupling to the old motor.

Module, shaft and relay

Buyer questions

Is the control module included?

No, the motor and the electronic module are separate parts and must be ordered by their own numbers.

Why is the motor running slowly?

Wear, supply issues or a faulty control module can all reduce motor performance.

Identification of W2.5B-04BX-12-03B-01 before ordering

Choose this motor when rotation is weak, noisy or absent; check the control module and power supply before replacing.
